Art.-Nr :
YT-6031-C1Sensor :
1/2.9''F/NEIN. :
2.4EFL :
1.51Optisches TTL :
15.15Gewindegröße :
M12*P0.5Sichtfeld (H/V/D) :
200/118/200Struktur :
6GLearn more about the parameters of the YT-6031-C1 fisheye lens | |
SENSOR SIZE |
1920*1080 |
WAVELENGTH | 400~700 |
FOCAL LENGTH (EFL) | 1.51mm |
F/NO (INFINITE) | 2.4 |
BACK FOCAL LENGTH | 3.44mm |
FLANGE BACK LENGTH | 2.24mm |
FIELD OF VIEW(D) | 200 |
FIELD OF VIEW(H) | 200 |
FIELD OF VIEW(V) | 118 |
TV DISTORTION | -43% |
THREAD SIZE | M12*P0.5 |
STRUCTURE |
6G |
CRA |
13° |
WAVEIENGTH |
Tavg>=88% @420-600 nm T=50% @650nm Tavg<=3% @ 700-1000 nm T<5% @1050 nm |
Good perspective effect:
YT-6031-C1 has a strong perspective effect. Able to make the object being photographed a huge aperture near the center of the lens, while the object away from the center is reduced, thus creating a unique perspective effect. "Fisheye" effect. This special perspective effect can enhance a sense of drama and art to a photo or video.
Interesting distortion effects:
Due to the corrective nature of the fisheye lens, it introduces some distortion effects, such as spherical distortion and line bending. These distortions can add a special creativity and variation to a photo or video, creating an interesting visual effect.
Explore creative possibilities:
YT-6031-C1 provides a different visual experience from traditional lenses, which can break the conventional shooting style and inspire the creative inspiration of photographers or videographers. It can help people try novel compositions, the difference between foreground and background, close-up theme shooting, etc., to expand the creative possibilities of photography and videography.
